24Gbps Industrial Ethernet Switch 12 Port DIN Rail Mounting Installation

Brand Name : 3onedata

Model Number : IES3012G

Certification : CE, FCC, RoHS

Place of Origin : Shenzhen, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 sets per month

Packaging Details : Carton

Material : Aluminum Alloy

Ethernet Ports : 12

Switch Capacity : 24Gbps

Input Power : 12~48VDC

Transmission Rate : 10/1001000Mbps

Operating Temperature : -40~75℃

Waterproof : IP40

Warranty : 5 years

Delivery Time : 7 Working Days

Contact Now

12-port full gigabit unmanaged DIN-rail mounting industrial Ethernet switch

Introduction

IES3012G series are 8/12-port full Gigabit layer 2 unmanaged industrial Ethernet switches. This series of products provide Gigabit copper port and SFP slot. They adopt DIN-Rail mounting to meet the requirements of different application scenes.



Power supply input is two independent power supply circuits, which can ensure the device normal operation when one of the power supplies breaks down. Design of DIP switch can achieve power supply alarm function. When power supply occurs link failure, ALARM indicator will be bright and send out alarm, meanwhile, alarm device connected to the relay will send out alarm for rapid scene troubleshooting. Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, rail transit, smart city, safety city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.



Specification



Standard

&

Protocol





IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX

IEEE 802.3ab for 1000Base-T

IEEE 802.3z for 1000Base-X


Interface



Copper port: 10/100/1000Base-T(X), RJ45, Automatic Flow Control, Full/half Duplex Mode, MDI/MDI-X Autotunning

SFP slot: 1000Base-SFP

Alarm port: 2-pin 7.62mm pitch terminal blocks, support 1 relay alarm output, current carrying capacity 5A@30VDC or 2A@250VAC



LED Indicator



Running Indicator, Port Indicator, Power Supply Indicator, Alarm Indicator



Switch

Property



Transmission mode: store and forward

MAC address: 8K

Packet buffer size: 4Mbit

Backplane bandwidth: 24G

Switch time delay: <10μs



Power

Requirement



12~48VDC, 4-pin 7.62mm pitch terminal blocks

dual power supply redundancy, reverse polarity protection, nonpolarity



Environmental

Limit



Operating temperature range: -40~75℃

Storage temperature range: -40~75℃

Relative humidity: 5%～95%(no condensation)



Physical

Characteristic



Housing: IP40 protection, metal

Installation: DIN-Rail mounting

Weight: ≤0.96kg

Dimension (W x H x D): 70mm×160mm×130mm



Industrial

Standard



IEC 61000-4-2 (ESD), Level 4

IEC 61000-4-4 (EFT), Level 4

IEC 61000-4-5 (Surge), Level 4

Shock: IEC 60068-2-27

Free fall: IEC 60068-2-32

Vibration: IEC 60068-2-6



Certification



CE, FCC, RoHS



Warranty



5 years




Dimension
Unit:mm

24Gbps Industrial Ethernet Switch 12 Port DIN Rail Mounting Installation



Ordering Information



Available Models Gigabit SFP Slot Gigabit Copper Port Power Supply Range
IES3012G-4GS 4 8

 12~48VDC

dual power supply
IES3012G-8GT  0 8
