Industrial 5 Port Gigabit Switch , Layer 2 Unmanaged Gigabit Ethernet Switch

Name: Industrial 5 Port Gigabit Switch Layer 2 Unmanaged Gigabit Ethernet Switch
Brand: 3onedata
Price: 1 USD

Buy cheap Industrial 5 Port Gigabit Switch , Layer 2 Unmanaged Gigabit Ethernet Switch product

Brand Name : 3onedata

Model Number : IES215

Certification : CE, FCC, RoHS

Place of Origin : Shenzhen, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 sets per month

Packaging Details : Carton

Material : Aluminum Alloy

Ethernet Ports : 5

Switch Capacity : 1.0Gbps

Input Power : 12~48VDC

Transmission Rate : 10/100Mbps

Operating Temperature : -40~75℃

Waterproof : IP40

Warranty : 5 years

Delivery Time : 7 Working Days

Contact Now

5-port 10/100M layer 2 unmanaged DIN-rail mounting industrial Ethernet switch

Introduction

IES215 series are 5-port 100M layer 2 unmanaged industrial Ethernet switches. This series include three types of products and provide 100M copper ports, 100M fiber ports. It adopts DIN-Rail mounting to meet the requirements of different application scenes.

Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, rail transit, smart city, safety city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.

Specification

Standard & Protocol	IEEE 802.3 for 10Base-TX IEEE 802.3u for 100Base-TX and 100Base-FX
Interface	Copper port: 10/100Base-T(X), RJ45, Automatic Flow Control, Full/half Duplex Mode, MDI/MDI-X Autotunning Fiber port: 100Base-FX, SC/ST/FC optional
LED Indicator	Port Indicator, Power Supply Indicator
Switch Property	Transmission mode: store and forward MAC address: 2K Packet buffer size: 1Mbit Backplane bandwidth: 1.6G Switch time delay: < 10μs
Power Requirement	12~48VDC, 3-pin 7.62mm pitch terminal blocks Support nonpolarity, reverse polarity protection
Environmental Limit	Operating temperature range: -40~75℃ Storage temperature range: -40~85℃ Relative humidity: 5%～95%(no condensation)
Physical Characteristic	Housing: IP40 protection, metal Installation: DIN-Rail mounting Dimension (W x H x D): 35mm×110mm×95mm Weight: ≤370g
Industrial Standard	IEC 61000-4-2 (ESD),Level 4 Air discharge: ±15kV Contact discharge: ±8kV IEC 61000-4-4 (EFT), Level 3 Power supply: ±2kV Ethernet interface: ±1kV IEC 61000-4-5 (Surge), Level 4 Power supply: common mode ±4kV, differential mode ±2kV Ethernet interface: ±4kV Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6
Certification	CE, FCC, RoHS
Warranty	5 years

Dimension
Unit:mm

Industrial 5 Port Gigabit Switch , Layer 2 Unmanaged Gigabit Ethernet Switch

Ordering Information

Available Models	100M Fiber Port	100M Copper Port	Power Supply Range
IES215	0	5	12~48VDC
IES215-1F	1	4
IES215-2F	2	3
