Industrial Din Rail Mount Ethernet Switch , Full Gigabit 6 Port Ethernet Switch

Brand Name : 3onedata

Model Number : IES206G-2GS

Certification : CE, FCC, RoHS

Place of Origin : Shenzhen, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 sets per month

Packaging Details : Carton

Material : Aluminum Alloy

Ethernet Ports : 6

Switch Capacity : 12Gbps

Input Power : 12~48VDC

Transmission Rate : 10/100/1000Mbps

Operating Temperature : -40~75℃

Waterproof : IP40

Warranty : 5 years

Delivery Time : 7 Working Days

Contact Now

6-port full gigabit unmanaged DIN-rail mounting industrial Ethernet switch

Introduction

IES206G-2GS is 6-port full Gigabit layer 2 unmanaged industrial Ethernet switches. The product provides Gigabit copper port and SFP slot. It adopts DIN-Rail or wall mounting to meet the requirements of different application scenes.



Power supply input is two independent power supply circuits, which can ensure the device normal operation when one of the power supplies breaks down. Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, rail transit, smart city, safety city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.

Specification



Standard

&

Protocol





IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX

IEEE 802.3ab for 1000Base-T

IEEE 802.3z for 1000Base-X


Interface



Copper port: 10/100/1000Base-T(X), RJ45, Automatic Flow Control, Full/half Duplex Mode, MDI/MDI-X Autotunning

SFP slot: 1000Base-SFP



LED Indicator



Running Indicator, Port Indicator, Power Supply Indicator



Switch

Property



Transmission mode: store and forward

MAC address: 1K

Packet buffer size: 1Mbit

Backplane bandwidth: 12G

Switch time delay: <10μs



Power

Requirement



12~48VDC

Dual power supply redundancy, nonpolarity, reverse polarity protection





Power

Consumption



No-load: 1.44W@24VDC

Full-load: 4.34W@24VDC

Environmental

Limit



Operating temperature range: -40~75℃

Storage temperature range: -40~85℃

Relative humidity: 5%～95%(no condensation)



Physical

Characteristic



Housing: IP40 protection, metal

Installation: DIN-Rail mounting

Weight: 0.69kg

Dimension (W x H x D): 53mm×138mm×110mm



Industrial

Standard



IEC 61000-4-2 (ESD), Level 4

Air discharge: ±15kV

Contact discharge: ±8kV



Shock: IEC 60068-2-27

Free fall: IEC 60068-2-32

Vibration: IEC 60068-2-6



Certification



CE, FCC, RoHS



Warranty



5 years




Dimension
Unit:mm

Industrial Din Rail Mount Ethernet Switch , Full Gigabit 6 Port Ethernet Switch



Ordering Information



Available Models Gigabit SFP Slot Gigabit Copper Port Power Supply Range
IES206G-2GS  2 4

 12~48VDC

dual power supply
