2 Port 100M Industrial Ethernet Media Converter Unmanaged Daughter Card

Name: 2 Port 100M Industrial Ethernet Media Converter Unmanaged Daughter Card
Brand: 3onedata
Price: 1 USD

Brand Name : 3onedata

Model Number : ECU101-1F

Certification : CE, FCC, RoHS

Place of Origin : Shenzhen, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 sets per month

Packaging Details : Carton

Ethernet Ports : 2

Input Power : 12VDC

Operating Temperature : -30~60℃

Warranty : 5 years

Delivery Time : 7 Working Days

Contact Now

2-port 100M industrial Ethernet media converter unmanaged daughter card
Introduction
ECU101-1F is 100M industrial media converter unmanaged daughter card. The product provides 100M copper port and fiber ports. It adopts slide-in mounting and could be matched with the media converter rack RACK2100.

The series adopt industrial grade design and support IEEE802.3/802.3u standard. Its copper port supports 10/100M, full/half duplex, MDI/MDI-X self-adaption, store-and-forward and cut-through mode setting.

The DIP switch could implement functions like LFP alarm, cut-through/store-and-forward modes and flow control. When the LFP function is turned on and the port has link failures, the LFP indicator will light up and send out an alarm to offer quick troubleshooting on the scene. Hardware adopts low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, railway transportation, smart city, safe city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.

Specification

Standard & Protocol	IEEE 802.3 for 10BaseT IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3x for Flow Control
Interface	Copper port: 10/100Base-T(X), RJ45, Automatic Flow Control, Full/Half Duplex Mode, MDI/MDI-X Autotunning Fiber port: 100Base-FX , SC/ST/FC optional
LED Indicator	STA Running Indicator, Port Indicator, LFP Indicator
Switch Property	Transmission mode: store-and-forward or cut-through MAC address: 1K Packet buffer size: 0.28M Backplane bandwidth: 0.6G Switch time delay: ＜10μs
Power Requirement	Input voltage: 12VDC
Power Consumption	No-load: 1.10W@12VDC Full-load: 1.52W @12VDC
Environmental Limit	Operating temperature range: -30~60℃ Storage temperature range: -30~60℃ Relative humidity: 5%～95% (no condensation)
Physical Characteristic	Installation: slide-in mounting Weight: 60g Dimension (W x H x D): 84.5mm×20.0mm×122.5mm
Certification	CE, FCC, RoHS
Warranty	5 years

Dimension
Unit:mm

2 Port 100M Industrial Ethernet Media Converter Unmanaged Daughter Card

Ordering Information

Type	100M Copper Port	Console	Power Supply
NMU	2	1	12VDC
